RE Lötschberg, Switzerland
RE Lötschberg
Built-to-print electrical distribution panels
Mors Smitt was selected by Alstom as the turn key supplier of the electrical distribution panels for the RE Lotschberg project.
Mors Smitt offered the following services: parts procurement, detail engineering, implementation modifications, manufacturing of the panels, 100% testing of the panels (in house test computer) and supply of the panels to the trainbuilder.
Our inhouse testcomputercheck offers the following functionalities:
- All connections (min, nom, max. voltage).
- Isolation resistance test.
- High voltage withstand test.
Train builder:
Operator:
Design:
Unique features:
|
Printed wiring (wire number and wire location) and cable ducts are applied. |
Turnkey solutions offered, also foreign parts purchasing. |
Mors Smitt D-U200 high reliability relays are used. |
| Scope of project RE Lötschberg: | |
| Project duration | 2007 - 2009 |
| No. of panels | 13 trains x 5 types panels 8 trains x 5 types panels |
| Circuit breakers | > 2.000 pieces |
| Relays | > 2.000 pieces |
| Contactors | > 1.500 pieces |
| Length of wiring | > 50 km |
| No. of crimp connections | > 46.000 pieces |
| No. of assembly hours | Ca. 3.150 hrs |
