FDG-U200 relay - Flashing, 2 solid state contacts

Name: FDG-U200 relay - Flashing, 2 solid state contacts
Brand: Own brand
Availability: InStock

Summary

Description

Plug-in electronic railway pulsing relay with two solid state contacts in counterphase. The pulse time and interval time are equal. There is no galvanic isolation between coil circuit and contacts.

The construction of the relay and choice of materials makes the FDG-U200 relay suitable to withstand low and high temperatures, shock & vibrating and dry to humid environments.

No external retaining clip needed as integrated ‘snap-lock’ will hold relay into socket under all circumstances and mounting directions.

Compact design and a wide range of sockets make the FDG-U200 relay an easy and flexible solution to use.

Application

These relay series are designed for demanding rolling stock applications. The FDG-U200 is designed to switch two sets of incandescent lamps (84 W maximum).

Features

Flashing relay (symmetrical)
Compact plug-in design
Solid state contacts 1 N/O and 1 N/C in counterphase
Fixed pulse and interval time
Flat, square and silver plated relay pins for excellent socket connection
Wide range sockets
Integrated snap lock
Transparent cover
Optional positive mechanical keying relay to socket

Benefits

Proven reliable
Long term availability
Easy to maintain
Low life cycle cost
No maintenance

Description

EN 50155 Electronic equipment used on rolling stock for railway applications
IEC 60571 Electronic equipment used on railway vehicles
IEC 60077 Electrical equipment for rolling stock in railway applications
IEC 60947 Low voltage switch gear and control gear
IEC 61373 Rolling stock equipment - Shock and vibration test
IEC 60947-5-4 Electromechanical components for control applications. This standard examines both coil and contact specifications in depth
NF F 16-101/102, TS 45545-2 Fire behaviour - Railway rolling stock
NF F 62-002 On-off contact relays and fixed connections
