Waterproof housings (DISCONTINUED)

NOA-1-192 Housing according panama canal recommendations (DISCONTINUED)

Summary
The NOA-housing system is a ‘Ready to mount’ system for bridge wing instruments built according the Panama Canal recommendations. The IP66 waterproof NOA-housing is suitable for a single 192 x 192 mm panel indicator. (model D3v192)

The user friendly dimmer knob, mounted on the front, provides an easy to adjust illumination intensity. This makes the instruments suitable for day/night operation.
As a result of the specific scale and pointer design of this instrument, combined with the ‘state of the art’ illumination system, it provides the largest and easiest to read scale printing in the market.

Model Description
NOA-1-192
Housing for 1 pc. 192x192 mm indicator
Designed according the Panama Canal recommendations

Remarks
Material Stainless steel
Finishing Powder coated
Connections 2 cable glands for cable entry
Dimmer The housing is equipped with a dimmer on the front.
Indicator Must be separately specified

General
Protection class IP66
Mounting
The housing is equipped with 4 mounting holes, for fixed mounting on panel or wall
