Waterproof housings (DISCONTINUED)
BCI Series waterproof housings (DISCONTINUED)
Summary
The Dv... and D3v... models bridge instruments can be supplied in a ‘ready to mount’ housing. The BCI housing system is available as a single instrument system, but also for 2, 3 or even 4 instruments in one housing.
The user friendly dimmer knob, mounted on the front, provides an easy to adjust illumination intesity. This makes the instruments suitable for day/night operation. Equipped with 2 cableglands and venting valve.
| Model | Description |
| BCI-1-96 |
Housing for 1 pc. 96 x 96 mm,
IP66 instrument |
| BCI-1-144 |
Housing for 1 pc. 144 x 144 mm,
IP66 instrument |
| BCI-1-192 |
Housing for 1 pc. 192 x 192 mm,
IP66 instrument |
| BCI-2-144 |
Housing for 2 pc. 144 x 144 mm,
IP66 instrument |
| BCI-3-96 |
Housing for 3 pc. 96 x 96 mm,
IP66 instrument |
| BCI-3-144 |
Housing for 3 pc. 144 x 144 mm,
IP66 instrument |
| BCI-4-96 |
Housing for 4 pc. 96 x 96 mm,
IP66 instrument |
| BCI-4-144 |
Housing for 4 pc. 144 x 144 mm,
IP66 instrument |
| Remarks | |
| Material | Stainless steel |
| Finishing | Powder coated |
| Connections | 2 cable glands for cable entry |
| Dimmer | The housing is equipped with a dimmer on the front. |
| Indicator | Must be separately specified |
| General | |
| Protection class | IP66 |
| Mounting |
The housing is equipped with swivel-
mounting bracket |
