RCI-400 Panorama rudder indicator (DISCONTINUED)

Summary
Servo-drive operated deckhead rudder indicator with 3 scales and pointers. Suitable for ceiling mounting. Integrated illumination dimmer and 2 cable glands.


Model Dimensions Weight
RCI-400
400 x 122 mm
3960 g
  (diameter x height)

Illumination
Dimmable pointer illumination
Dimmable scale illuminination

Input options Load
0…10 V 80 kΩ
0…12 V 80 kΩ
10…0…10 V 80 kΩ
12…0…12 V 80 kΩ
0…20 mA 100 Ω
4…20 mA 100 Ω
1…0…1 mA 1000 Ω
10…0…10 mA 100 Ω
20…0…20 mA 50 Ω


Scale
Background black / white
Inscription black / white / yellow
Coloured marks and bands On customer request
Company logo On customer request
Pointer options
Deflection 3 x 70o
Colour black / white / yellow
Other pointer colours on request

Temperature
Operation 0…55 °C
Storage -40…0…80 °C
Influence on accuracy 0.5 % / 10 °C

Vibration test
3…13.2 Hz 2 mm
13.2…100 Hz 0.7 g

General
Glass Iow-reflecting glass
Protection class IP40
Accuracy Class 1.5
Mounting On ceiling of the bridge
Standards
EN 60945:2002

Compliancy
ISO 20673:2007

Lloyds approval TA

MED directives:
Rudder A.1/4.20
