Measuring & monitoring relays (Obsolete)

XM-52M-VA500, 1 phase voltage monitoring relay

326002005
Summary

Electronic voltage monitoring relay, 2CO, 16A (AC1)

Modular voltage monittoring relay, rnage 12,5...500 VAC/DC, for general purpose applications in industry.
  • Modular housing
  • 2CO contacts
  • Monitored voltage serves also as supply voltage
  • Adjustable time delay
  • 35 mm DIN rail mounting
  • LED indicator (red / green / yellow), 3 states
  • Supply is done from monitored voltage
  • Possibility to set upper and lowel level of monitoring voltage
  • 3 modules, Din rail mounting
Specifications

0-10s

Product information request

Railway rolling stock
Railway signalling
Industry
Energy
Instruments
Maritime
Yes
Yes
