IB 200

This current sensor feeds 2 changeover relay contacts for a measured current from 16 A to 24 A. A potentiometer sets the relay pick-up from 15 A to 25 A. The maximum admissible shunt current is 50 A, with other versions available. An 110 VDC auxiliary supply is required for the measurement and relay command. The electronic device is housed in a B box and works with an external shunt (P929670). The reference socket for the B box module is EA103BFD. Devices are mounted on 35 mm rail conforming to EN 50022.
